Radeon Pro WX 9100 vs Arc A580
Radeon Pro WX 9100
Popular choices:
Arc A580
Popular choices:
Performance Spectrum - GPU
About G3D Mark
G3D Mark is a standard benchmark that measures graphics performance in real-world gaming scenarios. It simplifies comparing cards from different brands, where higher scores directly correlate with better fps and smoother gaming experiences.
Value Upgrade Path
This is the official ChipVERSUS Value Rating, comparing raw performance (G3D Mark) per dollar. Components placed above yours deliver better value for money.
Avg price is the current average price collected from markets across the web.
Performance Per Dollar Radeon Pro WX 9100
Performance Per Dollar Arc A580
Performance Comparison
About G3D Mark🏆 Chipversus Verdict
⚠️ Generational Difference
The Arc A580 is significantly newer (2023 vs 2017). The Arc A580 likely supports modern features like Ray Tracing, Tensor Cores, and DLSS/FSR upscaling, which act as force multipliers for performance. The Radeon Pro WX 9100 lacks this hardware feature set, limiting its longevity in modern titles despite any raw power similarities.
🚀 Performance Leadership
The Radeon Pro WX 9100 is the superior choice for raw performance. It leads with a 1.6% higher G3D Mark score and 100% more VRAM (16 GB vs 8 GB). This advantage makes it significantly better for higher resolutions (1440p/4K) and graphic-intensive titles compared to the Arc A580.
| Insight | Radeon Pro WX 9100 | Arc A580 |
|---|---|---|
| Performance | ✅Leading raw performance (+1.6%) | ❌Lower raw frame rates (-1.6%) |
| Longevity | 🛑Obsolete Architecture (2017 / GCN 5.0 (2017−2020)) | 🔮Strong Longevity (Generation 12.7 (2022−2023) / 6nm) |
| Ecosystem | Supports FSR Upscaling | Supports FSR Upscaling |
| VRAM | ✅ More VRAM (+100%) | 🎮 High Capacity (8 GB) |
| Efficiency | ⚡ Higher Power Consumption | 💡 Excellent Perf/Watt |
| Case Fit | Standard Size (267mm) | Standard Size (271mm) |
💎 Value Proposition
The Arc A580 offers a compelling cost-to-performance ratio. Priced at $179 versus $550 for the Radeon Pro WX 9100, it costs 67% less. While it maintains competitive performance, this results in a 202.5% higher cost efficiency score.
| Insight | Radeon Pro WX 9100 | Arc A580 |
|---|---|---|
| Cost Efficiency | ❌Lower cost efficiency | ✅Better overall value (+202.5%) |
| Upfront Cost | ⚠️Higher upfront cost ($550) | ✅More affordable ($179) |
Performance Check
Real-world benchmarks and performance projections based on comprehensive hardware analysis and comparative metrics. Values represent expected performance on High/Ultra settings at 1080p, 1440p, and 4K. Modeled using a Ryzen 7 7800X3D reference profile to minimize specific CPU bottlenecks.
Note: Performance behavior can vary per game. Specific architectures may perform better or worse depending on game engine optimizations and API implementation.
Technical Specifications
Side-by-side comparison of Radeon Pro WX 9100 and Arc A580
Radeon Pro WX 9100
The Radeon Pro WX 9100 is manufactured by AMD. It was released in July 10 2017. It features the GCN 5.0 architecture. The core clock ranges from 1200 MHz to 1500 MHz. It has 4096 shading units. The thermal design power (TDP) is 230W. Manufactured using 14 nm process technology. G3D Mark benchmark score: 12,250 points. Launch price was $1,599.
Arc A580
The Arc A580 is manufactured by Intel. It was released in October 10 2023. It features the Generation 12.7 architecture. The core clock ranges from 1700 MHz to 2000 MHz. It has 3072 shading units. The thermal design power (TDP) is 175W. Manufactured using 6 nm process technology. It features 24 dedicated ray tracing cores for enhanced lighting effects. G3D Mark benchmark score: 12,060 points.
Graphics Performance
The Radeon Pro WX 9100 scores 12,250 and the Arc A580 reaches 12,060 in the G3D Mark benchmark — just a 1.6% difference, making them near-identical in rasterization performance. The Radeon Pro WX 9100 is built on GCN 5.0 while the Arc A580 uses Generation 12.7, both on 14 nm vs 6 nm. Shader units: 4,096 (Radeon Pro WX 9100) vs 3,072 (Arc A580). Raw compute: 12.29 TFLOPS (Radeon Pro WX 9100) vs 12.29 TFLOPS (Arc A580). Boost clocks: 1500 MHz vs 2000 MHz.
| Feature | Radeon Pro WX 9100 | Arc A580 |
|---|---|---|
| G3D Mark Score | 12,250+2% | 12,060 |
| Architecture | GCN 5.0 | Generation 12.7 |
| Process Node | 14 nm | 6 nm |
| Shading Units | 4096+33% | 3072 |
| Compute (TFLOPS) | 12.29 TFLOPS | 12.29 TFLOPS |
| Boost Clock | 1500 MHz | 2000 MHz+33% |
| ROPs | 64 | 96+50% |
| TMUs | 256+33% | 192 |
| L2 Cache | 4 MB | 8 MB+100% |
Advanced Features (DLSS/FSR)
| Feature | Radeon Pro WX 9100 | Arc A580 |
|---|---|---|
| Upscaling Tech | FSR 1.0 (Software) | XeSS |
| Frame Generation | Not Supported | FSR 3 (Compatible) |
| Ray Reconstruction | No | No |
| Low Latency | AMD Anti-Lag | Standard |
Video Memory (VRAM)
The Radeon Pro WX 9100 comes with 16 GB of VRAM, while the Arc A580 has 8 GB. The Radeon Pro WX 9100 offers 100% more capacity, crucial for higher resolutions and texture-heavy games. Bus width: 128-bit vs 256-bit. L2 Cache: 4 MB (Radeon Pro WX 9100) vs 8 MB (Arc A580) — the Arc A580 has significantly larger on-die cache to reduce VRAM reliance.
| Feature | Radeon Pro WX 9100 | Arc A580 |
|---|---|---|
| VRAM Capacity | 16 GB+100% | 8 GB |
| Memory Type | GDDR6 | GDDR6 |
| Bus Width | 128-bit | 256-bit+100% |
| L2 Cache | 4 MB | 8 MB+100% |
Display & API Support
DirectX support: 12.1 (Radeon Pro WX 9100) vs 12 Ultimate (Arc A580). Vulkan: 1.3 vs 1.3. OpenGL: 4.6 vs 4.6. Maximum simultaneous displays: 4 vs 4.
| Feature | Radeon Pro WX 9100 | Arc A580 |
|---|---|---|
| DirectX | 12.1 | 12 Ultimate |
| Vulkan | 1.3 | 1.3 |
| OpenGL | 4.6 | 4.6 |
| Max Displays | 4 | 4 |
Media & Encoding
Hardware encoder: VCE 4.0 (Radeon Pro WX 9100) vs Xe Media Engine (Arc A580). Decoder: UVD 7.0 vs Xe Media Engine. Supported codecs: MPEG-2,H.264,HEVC,VP9 (Radeon Pro WX 9100) vs AV1,H.265,H.264,VP9 (Arc A580).
| Feature | Radeon Pro WX 9100 | Arc A580 |
|---|---|---|
| Encoder | VCE 4.0 | Xe Media Engine |
| Decoder | UVD 7.0 | Xe Media Engine |
| Codecs | MPEG-2,H.264,HEVC,VP9 | AV1,H.265,H.264,VP9 |
Power & Dimensions
The Radeon Pro WX 9100 draws 230W versus the Arc A580's 175W — a 27.2% difference. The Arc A580 is more power-efficient. Recommended PSU: 500W (Radeon Pro WX 9100) vs 600W (Arc A580). Power connectors: PCIe-powered vs 2x 8-pin. Card length: 267mm vs 271mm, occupying 2 vs 2 slots. Typical load temperature: 85°C vs 70.
| Feature | Radeon Pro WX 9100 | Arc A580 |
|---|---|---|
| TDP | 230W | 175W-24% |
| Recommended PSU | 500W-17% | 600W |
| Power Connector | PCIe-powered | 2x 8-pin |
| Length | 267mm | 271mm |
| Height | 111mm | 132mm |
| Slots | 2 | 2 |
| Temp (Load) | 85°C | 70-18% |
| Perf/Watt | 53.3 | 68.9+29% |
Value Analysis
The Radeon Pro WX 9100 launched at $2199 MSRP and currently averages $550, while the Arc A580 launched at $179 and now averages $179. The Arc A580 costs 67.5% less ($371 savings) at current market prices. Performance per dollar (G3D Mark / price): 22.3 (Radeon Pro WX 9100) vs 67.4 (Arc A580) — the Arc A580 offers 202.2% better value. The Arc A580 is the newer GPU (2023 vs 2017).
| Feature | Radeon Pro WX 9100 | Arc A580 |
|---|---|---|
| MSRP | $2199 | $179-92% |
| Avg Price (30d) | $550 | $179-67% |
| Performance per Dollar | 22.3 | 67.4+202% |
| Codename | Vega 10 | DG2-512 |
| Release | July 10 2017 | October 10 2023 |
| Ranking | #219 | #223 |
